About theJuice Goose iP-1520-RX 20A Web-Based Power Controller with RX Surge Protection
The Juice Goose iP-1520-RX is an advanced, intelligent power distribution unit that combines robust surge protection and noise filtration with comprehensive web-based control and monitoring for 20-amp equipment racks. This unit is engineered for IT data centers, professional AV installations, broadcast facilities, and any environment where remote power management is critical for uptime and operational efficiency. It provides a 20-amp power input distributed across multiple individually controllable outlets, allowing administrators to power cycle specific devices—such as a locked-up server, network switch, or DSP unit—from any location via a standard web browser. This remote reboot capability dramatically reduces response time to issues, often eliminating the need for physical access to remote equipment closets.Beyond remote switching, the iP-1520-RX incorporates the “RX” series multi-stage surge suppression and EMI/RFI noise filtration, actively cleaning the AC power line to protect sensitive electronics from voltage spikes and electrical noise that can cause data corruption, audio/video interference, or hardware damage. Its embedded web server delivers detailed, real-time monitoring data on aggregate and per-outlet current draw, voltage, power (kW), and energy consumption (kWh), providing invaluable insights for capacity planning and energy management. Network connectivity is via a built-in Ethernet port, with security ensured through features like password-protected access, configurable user roles, and support for secure protocols like HTTPS and SSH.Housed in a 1U or 2U steel rack-mount chassis, this PDU is built for continuous, reliable operation. It supports outlet power scheduling, can send email or SNMP alerts based on user-defined thresholds (e.g., overload, power loss), and allows for outlet grouping for batch control. The Juice Goose iP-1520-RX transforms a simple power strip into a networked power management appliance, providing unparalleled control, visibility, and protection for critical rack-mounted systems.
Key Features
- ocal, intranet and Internet power control
- Local fail safe sequencing and manual override
- On-board web server for easy set up, control, sequencing and monitoring
- Front panel indicators for network connection and surge protection function or fault.
- Amperage monitoring from 0.20 to 20.0 amps per power POD
- Administrator and User login options
- Automatic Power Cycle to reboot a network data router if network connection is lost
- Available Crestron control module
- Ten volt maximum line to neutral voltage surge
- One half volt maximum ground line voltage surge
- Transient Energy Absorption of 1,020 Joules
- AC line filtration of 60dB to 80dB @ 30MHz
Juice Goose iP-1520-RX 20A Web-Based Power Controller with RX Surge Protection Specs
Power Input & Protection Input Rating20 Amp, 120V AC Input ConnectorNEMA 5-20P Surge ProtectionMulti-stage, high joule rating (RX series) Noise FiltrationEMI/RFI filtering (RX series specification) Outlet Control & Configuration Total Outlets15 Outlet TypeIEC C13 Control FeatureIndividually Web-Switchable Outlets Outlet GroupingConfigurable for batch control Network & Monitoring Management InterfaceEmbedded Web Server (HTTP/HTTPS) Connectivity10/100/1000 Ethernet (RJ-45) Monitoring MetricsReal-time current (per outlet/total), voltage, power (kW), energy (kWh) Alerts & SchedulingEmail/SNMP alerts, programmable outlet scheduling Security & Physical SecurityPassword protection, multi-user access levels Form Factor1U or 2U, 19-inch Rackmount ChassisSteel
